    600m/Min Customized PP Spunbond Nonwoven Production Line High Speed

    Ask Lasest Price
    Brand Name : Chuzhou HH non-woven
    Model Number : HHM SMS
    Certification : CE
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : For detailed talk
    Delivery Time : For detailed talk
    • Product Details
    • Company Profile

    600m/Min Customized PP Spunbond Nonwoven Production Line High Speed


    customized spunmelt SMS PP Spunbond Nonwoven Fabric Making Machine Production Line From China


    Product category:


    • S Spunbonded nonwoven fabric
    • M Melt blown nonwoven fabri
    • SMMS Composite medical Non-Woven Fabric
    • SMS Composite nonwoven fabric)SS Spunbonded nonwoven fabric
    Installation:
    The seller will dispatch 4-7 engineers for installation, production line testing and customer training.
    Workers at the buyer's factory. Installation will take more than a month
    Operation training.
    The Seller shall pay the engineer's salary and visa fee. Buyer's notes payable
    Round-trip air tickets, accommodation and transportation, and food in the buyer's country,
    Medical, safety and related costs are incurred in the buyer's country. Meanwhile, the buyer
    Is there sufficient manpower, wiring and mounting tools around the control panel
    .

    Basic gram weight:SMS:9-100g/㎡ SMS:9-100g/㎡ S:10-150g/㎡


    SMS/SMMS/SSMMS PP Spunbond Nonwoven fabric production line

    SMS/SMMS/SSMMS PP Spunmelt Nonwoven fabric production line


    Product Details


    Model: SMS / SMMS / SSMS / SSMMS / SSSMMS


    Size: 1600mm / 2400mm / 3200mm


    Speed: 0-600m/min


    Gsm: 10-80g


    Filament D: 1.4-1.7d & 1.8-2.2d


    Nonwoven Absorbents Product:Absorbent cloths and wiping cloths,Media for oil absorption, Liquids (benzene, water, blood)


    3200 SMS Model

    Effective Width3200mm
    Weight Range9 - 100 g / ㎡
    Out put daily12 - 20 ton
    Machine speed≦ 350 m / min
    Transformer≈ 1600 KVA
    Power Consumption1300º - 1600 º / Ton
    Machine Size45 *25 * 12 M

    Spunbonded Nowovens Maily Applications
    Nonwoven Hygiene ProductCleaning wipes:Baby care , cosmetics ,etc.Baby and adult diapers:Top sheets , back sheets ,ears, tapes, landing zone;Female hygiene:Wings ,Top sheets
    Nonwoven Medical ProductSurgeon’s mask ,disposable garments ,Surgeon’s Cap,surgical drapes ,surgical sheet ,shoe covers , etc
    Nonwoven packaging ProductShopping bag ,rice backaging ,tea bag ,clothes packaging, etc.

    600m/Min Customized PP Spunbond Nonwoven Production Line High Speed


    Machine ModelReifenhauser Reicofil 3/4,Spunbond lines, spun-melt lins S, SS,SSS, SXS,SXXS,SMMS ,SMS ,SSMMS
    Machine Size18m-60m(L)*10m-31m(W)*10m-12m(H)
    Raw Material required

    PP(polypropylene),additives

    MFI/MFR:25-40g/10min(spunbonding process)

    MFI/MFR:800-2000g/10min (Melt-blowning process)

    Effective width1600mm,2400mm,3200mm,4000mm,4800mm customizable width by requirements
    Max Speed150m/mn-550m/min
    Transformer&Power consumption

    Transformer require:200KVA-3000KVA

    Power consumption :500KWH/Ton-1400KWH/Ton

    Output per year1500 Tons - 10000 Tons
    Products GSM8gsm-250 gsm
    Applications of products

    Industrial:Shopping bags, furniture ,agriculture ,packageing,etc

    Medical:Surgical gown /cap /sheet /mask ,etc

    Hygiene: Diapers ,sanitary ,napking , etc.


    SMS

    Effective Width

    (mm)

    Raw Material

    GSM Range

    (g/sqm)

    Max Speed

    (m/min)

    Annual Capacity

    (Ton / year )

    Daily Capacity

    ( Ton / day )

    1600mmPolypropylene(PP)

    9-100g

    3503200T9T
    2400mm5100T14T
    3200mm7000T19T
    4000mm8700T24T

    SMMS Model


    Working widthFabricPower inputConsumptionAnnual output/Year
    1600mm9-100G/㎡≈1500KVA1700º-1900º/Ton4000T
    2400mm9-100G/㎡≈1600KVA1700º-1900º/Ton6200T
    3200mm9-100G/㎡≈2200KVA1700º-1900º/Ton8400T
    4000mm9-100G/㎡≈2500KVA1700º-1900º/Ton10500T
    4800mm9-100G/㎡≈2630KVA1700º-1900º/Ton12700T

    Parts of spunbonded nonwoven fabric production line:


    Recycle extrude→Main extruder→Filter→Metering pump→Monomer suction device→spinning box( Changzhou/ENKA/KASEN spinneret )→Quenching air chamber→stretching device→Web former→Calender→Winder→Slitter

    Spunbonded process and technical flow chart:

    Additive(Recycling off-cut fabric)→Raw material→Melting→Filtering→Measuring→Spinning→Cooling→Stretching→Web forming→Calendering→Winding→Cutting→Final product


    Parts of Melt blown nonwoven fabric production line:


    Main extruder→filter→Metering pump→Air heating system→Melt blown sprayer (ENKA sprayer)→Web former→Winder→Slitter


    Melt blown process and technical flow chart:

    Raw material →Melting→Filtering→Measureing→Air heating→Spraying→Web forming→Winding→Cutting→Final product





    Payment & Shipping Terms:


    Minimum Order Quantity:1SET
    Delivery Time:150Days
    Payment Terms:T/T,L/C,D/P
    Supply Ability:50 sets per year
    PortFOB Shanghai or Nanjing

    Main Component


    Suction amchine and color matching machine are mainly used to extract pp material and its dyeing

    Metering pump is used to control the output by calculating the amount of pp material

    Screw extruder is to heat PP material and extrude raw material

    Spinning box ,is one of most import parts of the non-woven fabric manufacturing machine. PP material through the spinning box is spun into countless strands of silk .

    Filter to filter the melted PP raw material and remove impurities

    The silk thread is spun through this box to achieve temperature control and constant temperature .



    Name: Spinning Box

    Orifice number:11019 for 1.6m , 17651 for 3.2m

    Orifice diameter:Φ0.45mm

    L/D=4:1

    Max temperature:300℃


    Fuction : for spining the PP flament.


    NameSpinning box
    Orifice number1109 for 1.6 m , 17651 for 3.2 m
    Orifice diameter¢0.45mm L/D 4 : 1
    Max temperature300℃
    FuctionFor spinning the PP flow


    Name:Main Extruder
    Brand:HHM
    Original:China
    Diameter:Φ135mm for 1.6m,Φ170mm for 3.2m,

    Max speed: 75r/min for 1.6m , 85r/min for 3.2m

    Motor:90kw for 1.6m , 132kw for 3.2m



    Exhibition Show




    High precisely CNC


    600m/Min Customized PP Spunbond Nonwoven Production Line High Speed


    Packaging Details


    NUDE PACKING , WOODEN CASE IS OPTIONAL. CASE PACKING:CARDING MACHINE, LAPPER AND ELECTRIC BOXES WOODEN CASE PACKAGED.

    OTHER MACHINES NUDE PACKAGING.


    600m/Min Customized PP Spunbond Nonwoven Production Line High Speed


    600m/Min Customized PP Spunbond Nonwoven Production Line High Speed


    FAQ
    1.Q:I already have one factory but there is a little difference in the size,for example the height can't meet 13m,only 12m?
    A:Don't be worry. Your machine could be customized.
    2.Q:How to make sure your machine's quality?how about the service?
    A:Each machine gets ISO9001:2008,CE, SGS. And warranty is one year. you can enjoy the service within production lifetime.
    3.Q:How can I get right machine for myself, if I have no ideal about it?
    A:Tell me what kind of fabric that you want, how much you want to produce and your factory szie etc. We will design for you.
